| Model FM | M50 | M75 | M100 | M200 | M400 | M600 |
| Output Energy | 0.5 J | 0.75 J | 1 J | 2 J | 4 J | 6 J |
|
No-load Voltage, Max. |
10 kV | 10 kV | 10 kV | 10 kV | 10 kV | 10 kV |
|
Output Voltage, @ 500 Ω |
5.3 kV | 5.5 kV | 5.5 kV | 5.5 kV | 5.5 kV | 5.5 kV |
| Effective Fence Length, Max.* | 5 km | 7.5 km | 10 km | 20 km | 40 km | 60 km |
| Lightning Protection | yes | yes | yes | yes | yes | yes |
